KA-L28-A
KA-L28-A Dual 8” Bi-Amp Active Line Array Speaker
KA-L28-A is a lightweight two-way active line array cabinet, perfectly matched with KA-L18-AS subwoofer for professional sound reinforcement.
Core Advantages
1. Lightweight Neodymium Driver Setup
Equipped with 1.4” neodymium HF driver (3.0” voice coil) + dual 8” neodymium woofers (2.5” voice coil). The neodymium magnet design cuts weight drastically to only 20.6KG for easy stacking and flying.
2. Powerful & Clear Sound Performance
It delivers 1100W RMS / 2200W peak power, hitting a max 135dB SPL. The 50Hz–20kHz full frequency response reproduces crisp highs and solid mids, with a controlled 100°×15° coverage angle for consistent long-distance audio delivery.
3. Integrated Bi-Amp Compact Design
Built-in bi-amplifier eliminates extra amplifiers, simplifying system wiring. Durable plastic cabinet features compact 294×569×491mm dimensions, with standard 8Ω impedance for seamless system matching.
Ideal Application Scenarios
Perfect for medium outdoor concerts, live music festivals, church events, auditoriums, clubs and indoor performance venues when paired with matching KA-L18-AS subwoofer.
Frequency Response
50Hz-20kHz
Maximum SPL
135 dB
Impedance
Peak Power
2200W peak
Rated Power
1100W RMS
HF Drivers
1 x 1.4''neo, 3.0'' v.c
MF Drivers
LF Driver
2 x 8'' neo , 2.5'' v.c
Voice Coil
Magnet Material
Diaphragm Material
Net Weight
20.6 KG
Dimensions
294*569*491 mm
Cabinet Material
plastic
Configuration
active
Origin
China
Warranty
3 years
